PTC-1稱重傳感器詳細信息請點擊：英國LCMsystems稱重傳感器：
產品品牌：英國LCMsystems（LOADCELL）
產品類別：不銹鋼輪輻式
產品系列：LCM純壓式PTC-1系列稱重傳感器
產品型號：PTC-1 5KN,PTC-1 10kN,PTC-1 25kN,PTC-1 50kN,PTC-1 100kN,PTC-1 200kN,PTC-1 300kN,PTC-1 500kN
PTC-1 750kN,PTC-11000kN,PTC-1 2000kN
英國LCMsystems PTC-1稱重傳感器特點
▲范圍5-2000kN
▲不銹鋼材質
▲環境密封IP66
▲薄型
▲高固有頻率
▲熱穩定性高
英國LCMsystems PTC-1稱重傳感器產品描述：在PTC-1系列稱重傳感器是基于傳統的低調或煎餅稱重傳感器原理。的內部結構是剪切網頁設計，提供高固有頻率，低撓曲和側和扭轉力優異。
在PTC-1是由不銹鋼構造的具有優異的耐腐蝕性。有一個可選的安裝基座可用，如果測力傳感器處于張力中使用所必需的。在安裝基座也構造由不銹鋼制成。
標準的稱重傳感器提供有一個整體的MIL規格。連接器，與相配合的連接器提供。
在PTC-1非常適合許多測試應用中，高穩定性和低高度是基本要求。
在PTC-1可以用任何的LCM系統范圍內的測力傳感器的儀器一起提供，并且可以提供校準作為一個完整的準備好了的系統。
英國LCMsystems PTC-1稱重傳感器技術指標
|
Rated Load (FSO)
|
5, 10, 25, 50, 100, 200, 300, 500, 750, 1000, 2000kN
|
|
Overload Range
|
150% FSO
|
|
Ultimate Breaking Load
|
> 300% FSO
|
|
Maximum Transverse Load
|
100% FSO
|
|
Maximum Permissible Dynamic Load
|
75% FSO (through centre thread only)
|
|
Output
|
2mV/V (±0.1%)
|
|
Zero Balance
|
0.02mV/V
|
|
Non-Linearity
|
≤±0.05% FSO
|
|
Hysteresis
|
≤±0.05% FSO
|
|
Non-Repeatability
|
≤±0.03% FSO
|
|
Transverse Load Effect (at 10% FSO)
|
≤±0.03% FSO
|
|
Excitation Voltage
|
10vdc recommended (18vdc maximum)
|
|
Input Resistance
|
800Ω (5kN to 500kN), 430Ω (750kN to 2000kN)
|
|
Output Resistance
|
705Ω (5kN to 500kN), 352Ω (750kN to 2000kN)
|
|
Insulation Resistance
|
> 5GΩ@ 50vdc
|
|
Compensated Temperature Range
|
-10 to +40 °C
|
|
Operating Temperature Range
|
-10 to +70 °C
|
|
Storage Temperature Range
|
-20 to +80 °C
|
|
Zero Temperature Coefficient
|
≤±0.003% FSO/°C
|
|
Span Temperature Coefficient
|
≤±0.003% FSO/°C
|
|
Deflection at Rated Load
|
0.06mm (5kN to 25kN) 0.09mm (50kN to 100kN)
0.17mm (200kN to 300kN) 0.17mm (500kN)
0.23mm (750kN to 1000kN) 0.21mm (2000kN)
|
|
Environmental Protection Level
|
IP66
|
|
Weight (load cell only)
|
1.60kg (5kN to 25kN) 2.45kg (50kN to 100kN)
5.80kg (200kN to 300kN) 6.80kg (500kN)
16.5kg (750kN to 1000kN) 35kg (2000kN)
|
英國LCMsystems PTC-1稱重傳感器技術尺寸
Ranges 1500, 2000, 3000, 5000kg
Alloy steel nickel plated construction
Environmentally sealed to IP67
Can be supplied complete with mating spherical rod-end bearings
The PTC-1 series load cells are based on the conventional low profile or pancake load cell principle. The internal construction is a shear web design, offering high natural frequency, low deflection and excellent resistance to side and torsion forces.
The PTC-1 is constructed from stainless steel offering excellent corrosion resistance. There is an optional mounting base available, which is required if the load cell is to be used in tension. The mounting base is also constructed from stainless steel.
The standard load cell is supplied with an integral MIL spec. connector and supplied with a mating connector.
The PTC-1 is ideally suited to many testing applications, where high stability and low height are essential requirements.
The PTC-1 can be supplied with any of LCM Systems range of load cell instrumentation, and can be supplied calibrated as a complete ready to go system.
